Запчасти Komatsu PC138US-8 ЦИЛИНДР СТРЕЛЫ(ВНУТР. ЧАСТИ)(№-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

G1

707-01-XZC60

CYLINDER GROUP,L.H. (FINAL COATING)

G1

707-01-XZC70

CYLINDER GROUP,R.H. (FINAL COATING)

G1

707-01-XL660

CYLINDER GROUP,L.H.

G1

707-01-XL670

CYLINDER GROUP,R.H.

|$5

707-01-0L660

CYLINDER ASS'Y

1

707-13-10550

CYLINDER

2

721-58-70210

ROD

3

07020-00000

FITTING,GREASE

4

22B-70-23620

BUSHING

5

07145-00070

SEAL,DUST (KIT)

6

22B-70-23620

BUSHING

7

07145-00070

SEAL,DUST (KIT)

8

707-71-32470

COLLAR

9

07000-15095

O-RING (KIT)

10

707-71-70780

PLUNGER

11

707-35-91060

RING,BACK-UP (KIT)

12

707-27-10750

HEAD,CYLINDER

13

144-63-95170

SEAL,DUST (KIT)

14

07179-12084

RING,SNAP

15

707-51-70030

PACKING,ROD (KIT)

16

707-51-70650

RING,BUFFER (KIT)

17

707-52-90470

BUSHING

18

707-75-70110

RING,SNAP

19

07000-15095

O-RING (KIT)

20

707-35-91060

RING,BACK-UP (KIT)

21

705-17-04980

WASHER

22

01010-81465

BOLT

23

707-36-10760

PISTON

24

707-44-10250

RING,PISTON (KIT)

25

707-39-10550

RING,WEAR (KIT)

26

707-44-10911

RING

27

01310-01216

SCREW

28

707-34-60030

O-RING (KIT)

29

707-35-90730

RING,BACK-UP (KIT)

30

707-86-55160

TUBE,L.H.

30

707-86-55180

TUBE,R.H.

31

02896-11012

O-RING (KIT)

32

707-86-55170

TUBE,L.H.

32

707-86-55190

TUBE,R.H.

33

02896-11015

O-RING (KIT)

34

01010-80850

BOLT

35

01643-30823

WASHER

36

07000-13025

O-RING (KIT)

37

707-88-25460

BRACKET

38

707-88-21720

BAND

39

01010-81030

BOLT

40

01643-31032

WASHER

41

07372-21035

BOLT

42

01643-51032

WASHER

K

707-99-37170

SERVICE KIT
