Запчасти Komatsu PC138US-8 КОРОТК. РУКОЯТЬ(№-) РАБОЧЕЕ ОБОРУДОВАНИЕ

|$3

22B-944-0031

ARM ASS'Y

|$4

22B-944-0030

ARM ASS'Y

1

ARM

2

203-70-72210

BUSHING

2

22B-70-23630

BUSHING

3

203-70-42182

BUSHING

4

22B-70-23670

BUSHING

5

07020-00900

FITTING,GREASE

6

07020-00000

FITTING,GREASE

7

22B-70-12230

SEAL,DUST

8

21W-70-41440

SEAL,DUST

9

203-70-42121SA

PIN

9

203-70-42121

PIN

10

205-70-66580

PLATE

10

21W-70-11310

PLATE

11

01010-81230

BOLT

12

01643-31232

WASHER

13

21Y-70-14790

SPACER, 1.0MM

14

21Y-70-14820

SPACER, 2.0MM

15

07020-00675

FITTING,GREASE

16

202-70-52121

PIN

17

21Y-70-14710

SPACER, 1.0MM

18

205-70-66580

PLATE

18

21W-70-11310

PLATE

19

01010-81230

BOLT

20

01643-31232

WASHER

21

02756-20513

HOSE

22

02756-20413

HOSE

23

203-943-5620

ELBOW,L.H.

24

203-943-5130

ELBOW,R.H.

25

01010-81020

BOLT

26

01643-31032

WASHER

27

02782-10422

ELBOW

28

02783-10422

ELBOW

29

02896-11012

O-RING

30

02783-10522

ELBOW

31

02782-10522

ELBOW

32

02896-11015

O-RING

33

07002-12034

O-RING

34

07002-12434

O-RING

35

02756-20407

HOSE

36

22B-62-24440

HOSE, 730MM

37

07371-30500

FLANGE,SPLIT

38

01010-80830

BOLT

39

01643-50823

WASHER

40

07000-13022

O-RING
