Запчасти Komatsu PC138US-8 2 PIECE BOOM ВТОР. СТРЕЛА КРЕПЛЕНИЕS И КОРПУСS ( ATT)

1

203-973-5680

CLAMP

2

203-70-53391

PLATE

3

01010-81075

BOLT

4

01643-31032

WASHER

5

203-70-53391

PLATE

6

203-62-58810

CUSHION

7

201-97-36730

CLAMP

8

01010-81070

BOLT

9

01643-31032

WASHER

10

203-62-64370

BRACKET

11

22B-62-28770

CLAMP

12

22B-62-28760

CUSHION

13

01010-81035

BOLT

14

01643-31032

WASHER

15

22B-62-KA530

SEAT

16

01010-81035

BOLT

17

01643-31032

WASHER

18

22B-70-19130

CLAMP

19

22B-70-21930

CUSHION

20

01010-81085

BOLT

21

01643-31032

WASHER

22

22B-62-KA880

BRACKET

23

22B-70-19130

CLAMP

24

203-62-58810

CUSHION

25

203-70-53391

PLATE

26

203-62-58810

CUSHION

27

203-70-53391

PLATE

28

01010-81075

BOLT

29

01643-31032

WASHER

30

203-70-53391

PLATE

31

203-62-58810

CUSHION

32

201-973-6730

CLAMP

33

01010-81070

BOLT

34

01643-31032

WASHER

35

203-62-64370

BRACKET

36

203-973-5680

SEAT

37

20J-70-12191

BRACKET

38

07283-53444

SEAT

39

07283-33450

CLIP

40

01597-01009

NUT

41

01643-31032

WASHER

42

20J-70-12280

CLAMP

43

01010-81025

BOLT

44

01643-31032

WASHER

45

22B-62-28273

BRACKET

|45

22B-62-28611

BRACKET

46

07283-53444

SEAT

47

07283-33450

CLIP

48

01597-01009

NUT

49

01643-31032

WASHER

50

22B-62-28241

CLAMP

51

07095-00314

CLAMP

52

01010-81025

BOLT

53

01643-31032

WASHER

54

20E-62-32171

BRACKET

55

07283-52232

SEAT

56

07283-32236

CLIP

57

01597-01009

NUT

58

01643-31032

WASHER

59

20J-70-12280

CLAMP

60

01010-81025

BOLT

61

01643-31032

WASHER

62

20E-70-K1821

CLAMP

63

01010-81040

BOLT

64

01643-31032

WASHER
