Запчасти Komatsu PC138US-2E ОСНОВН. КЛАПАН (8-КЛАПАН) (9/) (ДЛЯ НАВЕСН. ОБОРУД И ОТВАЛ) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|$2

723-58-13801

VALVE ASS'Y

|$3

723-58-13800

VALVE ASS'Y

|$$3

THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.Y1664-01A0 TO Y1664-14A0.

|$5

723-50-51400

VALVE ASS'Y

1

BLOCK

2

SPOOL

3

723-50-51230

SPRING

4

723-50-51140

PLUG

5

07002-11623

O-RING

6

723-50-51150

FLANGE

7

07000-12011

O-RING

8

07000-11007

O-RING

9

01252-60620

BOLT

10

BALL

11

723-50-51160

PLUG

12

07000-11003

O-RING

13

07002-10823

O-RING

14

SCREW

15

07000-11008

O-RING

|$21

723-50-52200

VALVE ASS'Y

16

BLOCK

17

SPOOL

18

723-50-52130

RETAINER

19

723-50-52150

SPRING

20

723-56-31630

PLUG

21

07002-11623

O-RING

22

BALL

23

723-50-51160

PLUG

24

07000-11003

O-RING

25

07002-10823

O-RING

26

723-56-41620

ORIFICE

27

723-11-18190

PLUG

28

07002-11023

O-RING

29

SCREW

30

07000-11008

O-RING

31

07000-11007

O-RING

|$38

723-50-54100

VALVE ASS'Y

32

723-50-54110

BLOCK

33

723-56-31610

VALVE

34

723-56-31620

SPRING

35

723-56-31630

PLUG

36

07002-11623

O-RING

37

723-11-18190

PLUG

38

07002-11023

O-RING

39

07000-11009

O-RING

40

708-2L-25490

O-RING
