Запчасти Komatsu PC138US-2E ОСНОВН. НАСОС (/8) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|$1

708-1L-00551

PUMP ASS'Y

|$$2

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.Y1600-01A0 T0 Y1600-08A0.

|$3

708-1L-01431

PUMP SUB ASS'Y

1

708-2L-32110

SHAFT,FRONT

2

708-2L-32150

BEARING

3

708-2E-05040

WASHER KIT

3

WASHER, 3.1MM

3

WASHER, 3.0MM

3

WASHER, 2.9MM

3

WASHER, 2.8MM

4

708-25-12790

RING,SNAP

5

708-25-52861

SEAL,OIL

6

708-2L-22160

SPACER

7

04065-06825

RING,SNAP

|$15

708-2L-06360

BLOCK ASS'Y,FRONT

8

BLOCK,CYLINDER

9

PLATE,VALVE

10

720-68-19610

PIN

11

04065-04818

RING,SNAP

12

708-2L-23131

SEAT

13

708-2L-33160

SPRING

14

708-7L-13140

SEAT

15

708-2L-23351

GUIDE,RETAINER

16

708-2L-23360

PIN

17

708-2L-33340

RETAINER,SHOE

18

708-2L-33310

PISTON SUB ASS'Y

|$27

708-2L-04361

CRADLE ASS'Y

19

CRADLE

20

CAM,ROCKER
