Запчасти Komatsu PC138US-2 ЦИЛИНДР СТРЕЛЫ(ВНУТР. ЧАСТИ) (РУКОЯТЬ CRANE СПЕЦ-Я.)(№-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

G1

22B-63-X2570

BOOM CYLINDER ASS'Y,L.H. (YELLOW)

|G1

707-01-XA840

BOOM CYLINDER GROUP,L.H. (BLUE)

|G1

22B-63-X2580

BOOM CYLINDER ASS'Y,R.H. (YELLOW)

|G1

707-01-XA850

BOOM CYLINDER GROUP,R.H. (BLUE)

|1

22B-63-02500

CYLINDER ASS'Y,BOOM

1

22B-63-55741

CYLINDER

2

707-76-70230

BUSHING

3

07145-00070

SEAL,DUST (KIT)

4

07020-00000

FITTING,GREASE

5

707-27-10971

HEAD,CYLINDER

6

707-52-90470

BUSHING

7

707-51-70030

PACKING,ROD (KIT)

8

707-51-70630

RING,BUFFER (KIT)

9

707-71-32420

COLLAR

10

07000-15095

O-RING (KIT)

11

707-35-91060

RING,BACK-UP (KIT)

12

144-63-95170

SEAL,DUST (KIT)

13

07179-12084

RING,SNAP

14

01010-81465

BOLT

15

705-17-04980

WASHER

16

203-63-55720

ROD

17

707-76-70230

BUSHING

18

07145-00070

SEAL,DUST (KIT)

19

707-71-70700

PLUNGER

20

707-36-10571

PISTON

21

707-44-10280

RING,PISTON (KIT)

22

707-39-10520

RING,WEAR (KIT)

23

707-44-10911

RING

24

01310-01216

SCREW

25

707-34-60030

O-RING (KIT)

26

707-35-90730

RING,BACK-UP (KIT)

27

22B-63-55771

TUBE,L.H.

|27

22B-63-55871

TUBE,R.H.

28

07000-13025

O-RING (KIT)

29

01010-80850

BOLT

30

01643-50823

WASHER

31

707-88-96971

BAND

32

21Y-63-52192

BRACKET

33

01010-81035

BOLT

34

01643-51032

WASHER

35

01010-81030

BOLT

36

01643-31032

WASHER

K

707-99-37230

SERVICE KIT,BOOM CYLINDER
