Запчасти Komatsu PC138US-2 КАБИНА(№-) КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ

Схема запчастей Komatsu PC138US-2 - КАБИНА(№-) КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ
1
2
3
4
5
6
7
8
9
10
11
12
13
13
14
14
14
14
15
16
17
18
19
20
21
21
22
22

Артикул

Название

Примечание

Количество

|1

22B-54-00062

CAB ASS'Y,(DOOR SASH)

|1

22B-54-00060

CAB ASS'Y,(DOOR SASH)

|1

22B-54-00072

CAB ASS'Y,(DOOR SASH AND HALF GUARD)

|1

22B-54-00070

CAB ASS'Y,(DOOR SASH AND HALF GUARD)

|1

22B-54-00082

CAB ASS'Y,(DOOR SASH AND FULL GUARD)

|1

22B-54-00080

CAB ASS'Y,(DOOR SASH AND FULL GUARD)

|1

22B-54-00172

CAB ASS'Y,(DOOR SASH AND FULL GUARD) FIX

|1

22B-54-00170

CAB ASS'Y,(DOOR SASH AND FULL GUARD) FIX

1

22B-54-14211

CAB,(DOOR SASH)

|1

22B-54-14210

CAB,(DOOR SASH)

|1

22B-54-14221

CAB,(DOOR SASH AND HALF GUARD)

|1

22B-54-14220

CAB,(DOOR SASH AND HALF GUARD)

|1

22B-54-14231

CAB,(DOOR SASH AND FULL GUARD)

|1

22B-54-14230

CAB,(DOOR SASH AND FULL GUARD)

|1

22B-54-14151

CAB,(DOOR SASH AND FULL GUARD) FIX

|1

22B-54-14150

CAB,(DOOR SASH AND FULL GUARD) FIX

2

21J-54-14751

WINDOW,UPPER

3

20U-54-24971

DAM

4

22B-54-14630

WINDOW,LOWER

5

21J-54-16140

NUT

6

21J-54-16150

PACKING

7

01010-D0810

BOLT

8

01643-70823

WASHER

9

20U-54-24981

DAM

10

21J-54-14711

GLASS,R.H.

11

21J-54-14720

DAM

12

22B-54-14780

GLASS,REAR

13

20T-54-74870

NUT

14

20T-54-74880

GROMMET

15

22B-54-14820

RUBBER

16

01224-70612

SCREW

17

01023-20612

SCREW

18

22U-54-14660

TRIM

19

20U-54-25970

LOCK

20

20U-54-25980

LOCK

21

01224-70510

SCREW

22

01584-30504

NUT

Выбрано товаров: 37
