Запчасти Komatsu PC138US-2-A ЦИЛИНДР КОВША (ВНУТР. ЧАСТИ) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

G1

707-01-XG150

CYLINDER GROUP

|1

707-01-0G150

CYLINDER ASS'Y,BUCKET

1

707-13-10300

CYLINDER

2

707-76-65590

BUSHING

3

07145-00065

SEAL,DUST (KIT)

4

07020-00675

FITTING,GREASE

5

707-27-10910

HEAD,CYLINDER

6

707-52-90420

BUSHING

7

707-51-65030

PACKING,ROD (KIT)

8

707-51-65640

RING,BUFFER (KIT)

9

07000-15090

O-RING (KIT)

10

707-35-91020

RING,BACK-UP (KIT)

11

144-63-92170

SEAL,DUST (KIT)

12

07179-12079

RING,SNAP

13

01010-81465

BOLT

14

705-17-04980

WASHER

15

22B-63-75520

ROD

16

707-76-65590

BUSHING

17

707-77-65110

SEAL,DUST (KIT)

18

07020-00675

FITTING,GREASE

19

707-36-10800

PISTON

20

707-44-10180

RING,PISTON

21

707-39-10020

RING,WEAR (KIT)

22

707-44-10411

RING (KIT)

23

01310-01016

SCREW

24

707-34-55020

O-RING (KIT)

25

707-35-90610

RING,BACK-UP (KIT)

26

707-86-55220

TUBE

27

707-86-55230

TUBE

28

07000-13025

O-RING (KIT)

29

01010-80850

BOLT

30

01643-50823

WASHER

31

707-88-03250

BAND

32

707-88-03230

BRACKET

33

01010-81035

BOLT

34

01643-51032

WASHER

35

01010-81025

BOLT

36

01643-31032

WASHER

37

02896-11012

O-RING (KIT)

38

02896-11015

O-RING (KIT)

K

707-99-36330

SERVICE KIT,BUCKET CYLINDER
