Запчасти Komatsu PC130F-7 СТАРТЕР (.KW) (ВНУТР. ЧАСТИ) A

|$1

600-863-3210

STARTING MOTOR ASS'Y,(3.0KW)

1

KD024500-0141

CLUTCH ASS'Y,OVER RUNNING

2

KD024300-0030

FRONT BRACKET

3

KD121904-0230

PIN

4

KD024951-0070

PACKING

5

KD105050-0501

O-RING

6

KD024927-0030

HOLDER

7

KD024511-0040

PINION

8

KD123921-0150

WASHER

9

KD024610-0020

BRACKET,CENTER

10

KD024951-0100

PACKING

11

KD024200-0110

YOKE ASS'Y

12

KD024100-0080

ARMATURE

13

KD009271-3620

NAME PLATE

14

KD024921-0050

WASHER

15

KD024750-0100

BRUSH,HOLDER

16

KD024921-0010

WASHER

17

KD024711-0130

BRACKET,REAR

18

KD109211-0520

O-RING

19

KD104002-0100

PIN,STRAIGHT

20

KD047100-4810

MAGNETIC SWITCH A.

21

KD024951-0050

PACKING

22

KD047911-1300

SPRING

23

KD009001-5190

BOLT

24

KD009203-0010

BALL

25

KD009001-5370

BOLT

26

KD009252-0630

CAP,GUM

27

KD009001-5160

BOLT

28

KD009211-1440

O-RING

29

KD009011-2850

SCREW

30

KD047761-2741

COVER

31

KD009006-0660

NUT

32

KD009275-1430

PLATE,CAUTION
