Запчасти Komatsu PC130F-7 МОТОР ХОДА (/) Y

|$1

708-8F-00270

TRAVEL MOTOR

|$2

THIS ASSEMBLY CONSISTS OF ALL PARTS

|$3

SHOWN IN FIG. Y1651-01A0 AND Y1651-02A0

|$4

708-8F-04681

CASE SUB ASSY

1

CASE,MOTOR

2

PLUG

|$7

708-8F-04280

END COVER SUB ASSY

3

COVER,END

4

SPOOL

5

PLUG

6

PLUG

7

SPOOL

8

708-8F-34220

SPRING

9

708-8H-11530

PLUG

|$15

708-8H-11530

PLUG

10

07002-11423

O-RING

|$17

07002-11423

O-RING

11

702-21-55620

PLUG

12

07002-11423

O-RING

13

20B-27-11210

BLEEDER

14

702-73-02190

VALVE ASSY, RELIEF

15

708-8F-36611

SPRING

16

RING

17

708-8H-36121

SPRING

18

708-8F-36311

COVER, END

19

07000-13040

O-RING

20

700-93-11320

O-RING

21

07000-11009

O-RING

22

01252-61235

BOLT

23

708-8F-34120

VALVE

24

722-10-91130

SPRING

25

708-8F-34110

PLUG

26

07002-11823

O-RING

27

708-8E-16180

VALVE

28

708-8F-31650

PLUG

29

07000-11006

O-RING

30

07001-01006

RING,BACK-UP

31

07002-11223

O-RING

32

708-8F-31610

O-RING

33

07000-11009

O-RING

34

04020-01228

PIN,DOWEL

35

708-8F-31210

BOLT
