Запчасти Komatsu PC130F-7 ЦИЛИНДР КОВША SHEAR HEAD (ВНУТР. ЧАСТИ)(№J7-UP) Y

|$1

203-61-J2300

CYLINDER GROUP

|$2

===============

|$3

203-61-J2240

CYLINDER ASS'Y, BUCKET CYL SHEAR HEAD

1

203-61-J2220

CYLINDER

2

707-76-65210

BUSHING

3

07145-00065

SEAL, DUST (KIT)

4

07020-00675

FITTING, GREASE

5

707-27-90650

HEAD, CYLINDER

6

707-52-90361

BUSHING

7

707-51-60030

PACKING, ROD (KIT)

8

707-51-60650

RING, BUFFER (KIT)

9

07000-15080

O-RING (KIT)

10

707-35-90980

RING, BACK-UP (KIT)

11

707-56-60820

SEAL, DUST (KIT)

12

707-88-39490

RING

13

01010-81490

BOLT

14

705-17-04980

WASHER

15

707-88-39500

COLLAR

16

707-88-39480

PLATE

17

707-56-60740

SEAL, DUST (KIT)

18

202-63-75120

ROD

19

707-76-65220

BUSHING

20

707-77-65110

SEAL, DUST (KIT)

21

707-36-90170

PISTON

22

707-44-90150

RING, PISTON (KIT)

23

707-39-90050

RING, WEAR (KIT)

24

707-44-90911

RING

25

01310-01016

SCREW

26

07000-B5055

O-RING (KIT)

27

707-35-90920

RING, BACK-UP (KIT)

28

707-75-60110

RING, SNAP

29

203-61-J2230

TUBE

30

202-63-74580

TUBE

31

07000-13025

O-RING (KIT)

32

01010-80850

BOLT

33

01643-30823

WASHER

34

707-88-96280

BAND

35

202-63-74390

BRACKET

36

07372-21035

BOLT

37

01643-51032

WASHER

38

01010-81025

BOLT

39

01643-31032

WASHER

|$43

===============

|$44

707-99-27590

SERVICE KIT
