Запчасти Komatsu PC130F-7 ЦИЛИНДР КОВША (ВНУТР. ЧАСТИ) (№J8-UP) Y

|$1

707-01-0CJ11

CYLINDER ASS'Y, BUCKET

1

707-13-90330

CYLINDER, BUCKET

2

707-76-65210

BUSHING

3

07145-00065

SEAL, DUST (KIT)

4

70200-00675

FITTING, GREASE

5

707-27-90650

HEAD, CYLINDER

6

707-52-90361

BUSHING

7

707-51-60860

PACKING, ROD (KIT)

8

707-51-60650

RING, BUFFER (KIT)

9

07000-B5080

O-RING (KIT)

10

707-35-30810

RING, BACK-UP (KIT)

11

707-56-60800

SEAL, DUST (KIT)

12

01010-81495

BOLT

13

705-17-04980

WASHER

14

707-88-41710

COLLAR

15

707-88-39480

PLATE

16

707-56-60770

SEAL, DUST (KIT)

17

202-63-75120

ROD, PISTON

18

707-76-65220

BUSHING

19

707-77-65110

SEAL, DUST (KIT)

20

707-36-90170

PISTON

21

707-44-90150

RING, PISTON (KIT)

22

707-39-90050

RING, WEAR

23

707-44-90911

RING

24

01310-01016

SCREW

25

07000-B5055

O-RING (KIT)

26

707-35-30550

RING, BACK-UP (KIT)

27

707-75-60110

RING, SNAP

28

707-86-47450

TUBE

29

202-63-74580

TUBE

30

07000-13025

O-RING (KIT)

31

01010-80850

BOLT

32

01643-30823

WASHER

33

01010-80850

BOLT

34

01643-30823

WASHER

35

707-88-96280

BAND

36

202-63-74390

BRACKET

37

07372-21035

BOLT

38

01643-51032

WASHER

39

01010-81025

BOLT

40

01643-31032

WASHER

|$42

================

|$43

707-99-24730

SERVICE KIT
