Запчасти Komatsu PC130F-7 ЦИЛИНДР КОВША (ВНУТР. ЧАСТИ) (№J-J) Y

|$1

707-01-XAP60

CYLINDER GROUP,(FINAL COATING)

|$2

====================

|$3

707-01-0AP60

CYLINDER ASS'Y,BUCKET

1

707-13-90260

CYLINDER,BUCKET

2

707-76-65210

BUSHING

3

07145-00065

SEAL,DUST (KIT)

4

07020-00675

FITTING,GREASE

5

707-27-90920

HEAD,CYLINDER

6

707-52-90360

BUSHING

7

707-51-60030

PACKING,ROD (KIT)

8

707-51-60650

RING,BUFFER (KIT)

9

07000-15080

O-RING (KIT)

10

707-35-90980

RING,BACK-UP (KIT)

11

141-63-93270

SEAL,DUST (KIT)

12

07179-12074

RING,SNAP

13

01010-81465

BOLT

14

705-17-04980

WASHER

15

202-63-75120

ROD

16

707-76-65220

BUSHING

17

707-77-65110

SEAL,DUST (KIT)

18

07020-00675

FITTING,GREASE

19

707-36-90170

PISTON

20

707-44-90150

RING,PISTON (KIT)

21

707-39-90050

RING,WEAR (KIT)

22

707-44-95911

RING

23

01310-01016

SCREW

24

07000-B5055

O-RING (KIT)

25

707-35-90920

RING,BACK-UP (KIT)

26

707-86-47450

TUBE

27

202-63-74580

TUBE

28

07000-13025

O-RING (KIT)

29

01010-80850

BOLT

30

01643-30823

WASHER

31

01024-80850

BOLT

32

707-88-21710

BAND

33

707-88-25090

BRACKET

34

07375-21035

BOLT

35

01010-81025

BOLT

36

01643-31032

WASHER

|$40

====================

|$41

707-99-27500

SERVICE KIT
