Запчасти Komatsu PC130F-7 ЦИЛИНДР РУКОЯТИ(УДЛИНН. REACH) Y

|$1

707-01-XF030

CYLINDER ASS'Y,ARM

|$2

==========

|$3

707-01-0F030

CYLINDER ASS'Y

1

707-13-11640

CYLINDER,ARM

2

707-76-70240

BUSHING

3

07145-00070

SEAL,DUST (KIT)

4

707-27-11971

HEAD,CYLINDER

5

707-52-90501

BUSHING

6

707-51-75030

PACKING,ROD (KIT)

7

707-51-75640

RING,BUFFER (KIT)

8

707-71-32530

COLLAR

9

07000-15105

O-RING (KIT)

10

707-35-91150

RING,BACKUP (KIT)

11

07000-15105

O-RING (KIT)

12

707-35-91150

RING,BACKUP (KIT)

13

707-56-75740

SEAL,DUST (KIT)

14

07179-13089

RING,SNAP

15

01010-81670

BOLT

16

01643-51645

WASHER

17

707-58-75670

ROD

18

707-71-80230

PLUNGER

19

04260-00635

BALL

20

707-71-91270

CAP

21

707-76-70240

BUSHING

22

07145-00070

SEAL,DUST (KIT)

23

707-71-60870

PLUNGER

24

707-36-11851

PISTON

25

707-44-11280

RING,PISTON (KIT)

26

707-39-11530

RING,WEAR (KIT)

27

707-44-11920

RING

28

01310-01216

SCREW

29

07000-15070

O-RING (KIT)

30

707-35-90360

RING,BACKUP (KIT)

31

707-83-13010

VALVE

32

07750-01628

SPRING

33

707-87-14071

PLUG

|$37

707-87-14070

PLUG

34

07002-12034

O-RING (KIT)

35

707-86-47480

TUBE

36

707-87-13570

ELBOW

37

07000-13025

O-RING (KIT)

38

01010-80850

BOLT

39

01643-50823

WASHER

40

01010-80855

BOLT

41

01643-30823

WASHER
