Запчасти Komatsu PC130F-7 ЦИЛИНДР СТРЕЛЫ(ДЛЯ HARVESTER)(J9-UP)(500 ЧАСОВ) T

|$1

707-01-XG670

CYLINDER GROUP, L.H

|$2

707-01-XG680

CYLINDER GROUP, R.H

|$3

=============

|$4

707-01-0G670

CYLINDER ASS'Y, L.H

|$5

707-01-0G680

CYLINDER ASS'Y, R.H

1

707-13-10540

CYLINDER

2

203-63-55521

ROD, PISTON

3

21K-70-71320

BUSHING

4

07145-00070

SEAL, DUST (KIT)

5

07020-00675

FITTING GREASE

6

21K-70-71320

BUSHING

7

07145-00070

SEAL, DUST (KIT)

8

707-27-10971

HEAD, CYLINDER

9

144-63-95170

SEAL, DUST (KIT)

10

07179-12084

RING, SNAP

11

707-52-90470

BUSHING

12

707-51-70030

PACKING, ROD (KIT)

13

707-51-70640

RING, BUFFER (KIT)

14

707-35-91060

RING, BACK-UP (KIT)

15

07000-15095

O-RING (KIT)

16

01010-81465

BOLT

17

705-17-04980

WASHER

18

707-36-10760

PISTON

19

707-44-10280

RING, PISTON (KIT)

20

707-39-10550

RING, WEAR (KIT)

21

707-44-10911

RING

22

707-34-60030

O-RING (KIT)

23

707-35-90730

RING, BACK-UP (KIT)

24

01310-01216

SCREW

25

707-86-47460

TUBE, L.H

|$31

707-86-47470

TUBE, R.H

26

202-63-54380

TUBE, L.H

|$33

202-63-54480

TUBE, R.H

27

01010-80850

BOLT

28

01643-30823

WASHER

29

07000-13025

O-RING (KIT)

30

707-88-25110

BRACKET

31

707-88-21720

BAND

32

07372-21035

BOLT

33

01643-51032

WASHER

34

01010-81030

BOLT

35

01643-31032

WASHER

|$43

=============

|$44

707-99-37300

SERVICE KIT
