Запчасти Komatsu PC130F-7 РУКОЯТЬ (. HD) (РУКОЯТЬ И ПАЛЕЦ) T

|$1

203-943-7221

ARM GROUP

1

203-943-7111

ARM

2

203-70-72210

BUSHING

|$4

203-70-56130

BUSHING

3

203-70-42182

BUSHING

4

203-70-56150

BUSHING

5

07020-00900

FITTING

6

07020-00000

FITTING

7

07096-20508

HOSE

8

07096-20408

HOSE

9

203-943-5620

ELBOW, L.H

10

203-943-5130

ELBOW, R.H

11

01010-81020

BOLT

12

01643-31032

WASHER

13

07235-10422

ELBOW

14

07230-20422

UNION

15

07230-20522

UNION

16

07235-10522

ELBOW

17

07002-22034

O-RING

18

07002-22434

O-RING

19

07096-20414

HOSE

20

07096-20514

HOSE

21

203-70-42121

PIN

22

205-70-66580

PLATE

23

01010-81230

BOLT

24

01643-31232

WASHER

25

07020-00675

FITTING

26

21Y-70-14830

SPACER, 1.0MM

27

21Y-70-14840

SPACER, 2.0MM

28

202-70-52121

PIN

29

21Y-70-14710

SPACER, 1.0MM

30

205-70-66580

PLATE

31

01010-81230

BOLT

32

01643-31232

WASHER

33

22B-70-12230

SEAL

|$36

07145-00070

SEAL

|$37

07145-00070

SEAL

34

21W-70-41440

SEAL DUST

|$39

21W-70-41440

SEAL DUST

35

07371-30640

FLANGE

36

07000-13025

O-RING

37

07372-21035

BOLT

38

01643-51032

WASHER
