Запчасти Komatsu PC130F-7 ЦИЛИНДР СТРЕЛЫ(ДЛЯ SHEAR HEAD)(J7-UP)( HOUR) T

|$1

707-01-XCJ90

CYLINDER GROUP, L.H

|$2

707-01-XCK00

CYLINDER GROUP, R.H

|$3

=============

|$4

707-01-0CJ90

CYLINDER ASS'Y

1

707-13-95140

CYLINDER

2

21K-70-71320

BUSHING

3

07145-00070

SEAL, DUST (KIT)

4

07020-00675

FITTING, GREASE

5

707-27-95650

HEAD, CYLINDER

6

707-52-90421

BUSHING

7

707-51-65030

PACKING, ROD (KIT)

8

707-51-65650

RING, BUFFER (KIT)

9

07000-15085

O-RING (KIT)

10

707-35-90970

RING, BACK-UP (KIT)

11

707-56-65740

SEAL, DUST (KIT)

12

07179-12079

RING, SNAP

13

01010-81465

BOLT

14

705-17-04980

WASHER

15

202-63-55120

ROD, PISTON

16

21K-70-71320

BUSHING

17

07145-00070

SEAL, DUST (KIT)

18

707-36-95040

PISTON

19

707-44-95150

RING, PISTON (KIT)

20

707-39-95030

RING, WEAR (KIT)

21

707-44-95911

RING

22

01310-01016

SCREW

23

707-34-55030

O-RING (KIT)

24

707-35-90610

RING, BACK-UP (KIT)

25

707-86-47420

TUBE, L.H

|$30

707-86-47430

TUBE, R.H

26

202-63-54380

TUBE, L.H

|$32

202-63-54480

TUBE, R.H

27

07000-13025

O-RING (KIT)

28

01010-80850

BOLT

29

01643-30823

WASHER

30

707-88-96950

BAND

31

707-88-95480

BRACKET

32

07372-21035

BOLT

33

01643-51032

WASHER

34

01010-81030

BOLT

35

01643-31032

WASHER

|$42

=============

|$43

707-99-27460

SERVICE KIT
