Запчасти Komatsu PC130F-7 ОСНОВН. КОНСТРУКЦИЯ (КАБИНА)(ПОЛ)(УПРАВЛ. НАВЕСН. ОБОРУД.)(ATT) K

1

702-16-01230

PILOT VALVE

2

22U-54-25660

SEAL

3

22U-43-21470

SEAT

4

01010-81025

BOLT

5

01643-31032

WASHER

6

01643-31032

WASHER

7

20Y-62-25360

BRACKET

8

01010-D1025

BOLT

9

01643-71032

WASHER

10

22U-43-21461

PEDAL

11

01010-D1045

BOLT

12

01643-71032

WASHER

13

22U-43-21480

PLATE

14

01010-D1030

BOLT

15

01643-71032

WASHER

16

22U-54-25541

PLATE

17

01010-81020

BOLT

18

01643-31032

WASHER

19

22U-54-25670

CAP

20

21W-62-43980

ELBOW

21

02896-11008

O-RING

22

07000-12011

O-RING

23

20Y-62-43470

NIPPLE

24

02896-11008

O-RING

25

11Y-62-12140

NIPPLE

26

02896-11008

O-RING

27

07000-12011

O-RING

|$28

203-62-71651

HOSE

28

208-62-72650

HOSE

29

208-62-72940

HOSE

30

208-62-72630

HOSE

31

208-62-72310

HOSE

32

20Y-62-22790

BAND (RED)

33

20Y-62-22810

BAND (YELLOW)

34

20Y-62-22820

BAND (BLUE)

35

08034-20519

BAND

36

04435-51210

CLIP

37

01583-51408

NUT
