Запчасти Komatsu PC130F-7 ГИДР. БАК. (ДЛЯ HARVESTER)(J9-UP) H

1

203-60-J1230

TANK

2

203-60-31160

TUBE

3

203-60-31100

ELBOW ASS'Y

4

423-60-45461

ELEMENT

5

07069-23200

STRAINER

6

21W-60-41170

VALVE ASS'Y

7

20X-60-22140

SPRING

8

07000-15155

O-RING

9

20Y-60-21311

STRAINER

10

203-60-61161

ROD

11

12R-60-11230

SPRING

12

07000-15180

O-RING

13

203-60-J1220

COVER

14

01010-81225

BOLT

15

01643-31232

WASHER

16

20Y-60-21340

GASKET

|$17

198-60-55510

BREATHER

17

421-60-35170

ELEMENT

18

421-60-35180

COVER

19

421-60-35190

NUT

20

BODY

21

VALVE ASS'Y

22

O-RING

23

CASE

24

20Y-60-42210

FILLER, NECK

25

01252-70516

BOLT

26

01601-20513

WASHER

27

208-60-41211

CAP ASS'Y

|$29

20Y-60-42220

CAP ASS'Y

|$30

208-60-41221

BREATHER, CAP

|$31

20Y-60-42170

CAP

|$32

20Y-60-21470

ELEMENT

28

07044-12412

PLUG

29

07002-02434

O-RING

30

07270-61410

TUBE

31

07285-00155

CLIP

32

203-00-17210

MARK, TRIANGLE

33

203-00-17220

MARK, KEY

34

203-62-J1850

BLOCK

35

203-62-J1860

COVER

36

01010-81275

BOLT

37

01643-31232

WASHER

38

01010-81635

BOLT

39

01643-31645

WASHER
