Запчасти Komatsu PC130-8M0 КОМПОНЕНТЫ ДВИГАТЕЛЯ (ОСНОВН. НАСОС) (/9) B [КОМПОНЕНТЫ ДВИГАТЕЛЯ]

-

708-3D-00020

PUMP ASSEMBLY

-

708-3D-01020

PUMP SUBASSEMBLY

1

708-2L-34120

SLIDER

-

708-3D-04610

VALVE ASSEMBLY, PC

2

PISTON ASSEMBLY, SERVO, SERVO

3

SEAL

4

PLUG

5

708-2L-35760

BALL

6

708-2L-35770

PLUG

7

SEAL

8

708-3D-15320

PIN

9

708-2L-35860

SPOOL

10

708-2L-35630

RETAINER

11

708-2L-35641

SEAT

12

708-3D-15410

SPRING

13

708-2L-35730

SPRING

14

708-2L-35650

SEAT

15

708-3D-15420

SPRING

16

SCREW

17

07000-B3034

O-RING

18

708-2L-35210

RING, BACK-UP

19

SEAL

20

708-2L-35270

PLUG

21

07000-B2011

O-RING

22

07000-B3045

O-RING

23

708-2L-35750

RING, BACK-UP

24

708-2L-34230

COVER

25

01580-10806

NUT

26

708-2L-35290

NUT

27

708-2L-35670

RING, WIRE

28

01252-61440

BOLT, HEXAGON SOCKET HEAD
