Запчасти Komatsu PC130-8M0 ЦИЛИНДР КОВША T [РАБОЧЕЕ ОБОРУДОВАНИЕ]

-

707-E1-01740

CYLINDER ASSEMBLY

1

707-13-95160

CYLINDER

2

707-58-65A30

ROD, PISTON

3

707-76-65210

BUSHING

4

07145-00065

SEAL, DUST\((K04)\)

5

07020-00675

FITTING, GREASE

6

707-76-65220

BUSHING

7

707-77-65110

SEAL, DUST\((K04)\)

8

07020-00675

FITTING, GREASE

9

707-27-95650

HEAD, CYLINDER

10

707-56-65740

SEAL, DUST\((K04)\)

11

07179-12079

RING, SNAP

12

707-51-65860

PACKING, ROD\((K04)\)

13

707-51-65650

RING, BUFFER\((K04)\)

14

07000-B5085

O-RING\((K04)\)

15

707-35-30860

RING, BACK-UP\((K04)\)

16

707-52-90421

BUSHING

17

707-75-65110

RING, SNAP

18

01010-81465

BOLT

19

705-17-04980

WASHER

20

707-36-95040

PISTON

21

707-44-95150

RING, PISTON\((K04)\)

22

707-39-95030

RING, WEAR\((K04)\)

23

707-34-55030

O-RING\((K04)\)

24

707-35-30580

RING, BACK-UP\((K04)\)

25

707-44-95911

RING

26

01310-01016

SCREW

27

707-86-56110

TUBE

28

02896-61015

O-RING\((K04)\)

29

707-88-51490

BRACKET

30

707-88-21730

BAND

31

07372-21035

BOLT

32

01643-51032

WASHER

33

01010-80850

BOLT

34

01643-30823

WASHER

35

01010-81025

BOLT

36

01643-31032

WASHER

37

07000-13025

O-RING\((K04)\)
