Запчасти Komatsu PC130-8M0 ЦИЛИНДР РУКОЯТИ T [РАБОЧЕЕ ОБОРУДОВАНИЕ]

-

707-E1-01690

CYLINDER ASSEMBLY

1

707-13-11920

CYLINDER

2

707-58-75990

ROD, PISTON

3

707-76-70240

BUSHING

4

07145-00070

SEAL, DUST\((K03)\)

5

707-76-70240

BUSHING

6

07145-00070

SEAL, DUST\((K03)\)

7

707-71-34420

COLLAR

8

707-35-31060

RING, BACK-UP\((K03)\)

9

07000-B5105

O-RING\((K03)\)

10

707-71-70810

PLUNGER

11

707-71-80330

PLUNGER

12

04260-00635

BALL, STEEL

13

707-71-91270

CAP

14

707-27-11750

HEAD, CYLINDER

15

707-56-75740

SEAL, DUST\((K03)\)

16

07179-13089

RING, SNAP

17

707-51-75860

PACKING, ROD\((K03)\)

18

707-51-75650

RING, BUFFER\((K03)\)

19

07000-B5105

O-RING\((K03)\)

20

707-35-31060

RING, BACK-UP\((K03)\)

21

707-52-90501

BUSHING

22

707-75-75110

RING, SNAP

23

01010-81670

BOLT

24

01643-51645

WASHER

25

707-36-11851

PISTON

26

707-44-11250

RING, PISTON\((K03)\)

27

707-39-11530

RING, WEAR\((K03)\)

28

707-44-11920

RING

29

01310-01216

SCREW

30

07000-B5070

O-RING\((K03)\)

31

707-35-30700

RING, BACK-UP\((K03)\)

32

707-83-13010

VALVE

33

07750-01628

SPRING

34

707-87-14070

PLUG

35

07002-12034

O-RING\((K03)\)

36

707-86-56050

TUBE

37

02896-61018

O-RING\((K03)\)

38

01010-80850

BOLT

39

01643-30823

WASHER
