Запчасти Komatsu PC130-8M0 СТРЕЛА (MM) (ЛАМПА РАБОЧ. ОСВЕЩЕНИЯ И ПАЛЕЦ) T [РАБОЧЕЕ ОБОРУДОВАНИЕ]

|$1

ЧўЈєґЛБР±н°ьАЁТФПВ№жёсЎЈ

|$2

4600mm

|$3

4600mmЈ¬ґш1ёщёЅјУЦґРР»ъ№№№ЬВ·

|$4

Note: This list covers following

|$5

4600mm

|$$6

4600mm

With 1-additional Actuator Piping

1

20Y-06-43230

WORKING LAMP ASSEMBLY

-

20Y-06-D1870

WORKING LAMP ASSEMBLY

-

421-06-23330

BULB, 70WATT

-

20Y-06-D1890

BULB, 70WATT

2

20Y-06-21551

BRACKET

3

01010-81225

BOLT

4

01643-31232

WASHER

5

203-06-11140

WIRE

6

08193-21012

CLIP

7

01010-81225

BOLT

8

01643-31232

WASHER

9

04434-51012

CLIP

10

01010-81020

BOLT

11

01643-31032

WASHER

12

08034-40521

BAND

13

22B-70-22550

PIN

14

22B-70-22570

PLATE

15

01010-81235

BOLT

16

01643-31232

WASHER

17

20U-70-31340

SPACER, T=1.0MM

-

20U-70-31330

SPACER, T=0.5MM

18

203-70-42121

PIN

19

205-70-66580

PLATE

20

01010-81230

BOLT

21

01643-31232

WASHER

22

21Y-70-14830

SPACER, T=1.0MM
