Запчасти Komatsu PC130-8M0 МЕХАНИЗМ ПОВОРОТА И МОТОР (МОТОР ПОВОРОТА) (/) N [ПОВОРОТН. КРУГ И ITS КОМПОНЕНТЫ]

-

203-26-80500

SWING MACHINERY ASSEMBLY

-

203-26-85000

SWING MACHINERY ASSEMBLY

-

706-7C-01040

MOTOR ASSEMBLY

-

706-7C-03040

MOTOR SUBASSEMBLY

1

706-7C-41510

SHAFT, DRIVE

2

706-73-43880

BEARING

3

706-7C-41610

PLATE

4

706-73-43890

BEARING

5

706-7C-05110

SPACER KIT

-

SPACER, T=1.5MM

-

SPACER, T=1.7MM

-

SPACER, T=1.9MM

-

SPACER, T=2.1MM

-

SPACER, T=2.3MM

6

04064-03515

RING, SNAP

7

708-7T-12330

SEAL, OIL

8

04065-04518

RING, SNAP

9

706-7C-41110

CYLINDER BLOCK

10

706-7C-41310

PLATE, VALVE

11

720-68-19610

PIN

12

706-7C-41210

SHAFT, CENTER

13

706-7C-41410

RING, CENTER

14

706-7C-41420

SPRING

15

706-7C-41910

RETAINER, SHOE

16

706-73-42270

SCREW

17

706-7C-41740

PISTON SUBASSEMBLY

18

706-7C-91210

PLATE

19

706-7C-91220

DISC

20

706-7C-91110

PISTON, BRAKE

21

706-7C-91120

RING, BRAKE

22

07000-12110

O-RING

23

07000-12130

O-RING

24

706-7C-91310

SPRING
