Запчасти Komatsu PC130-8 ГИДРАВЛ МАСЛ. БАК(№C-) ГИДРАВЛ МАСЛ. БАК

1

203-60-11111

Tank

2

203-60-31160

Tube

3

203-60-31100

Elbow Assembly

4

14X-60-31150

Element

5

07069-23200

Strainer

6

21W-60-41170

Valve Assembly

7

20X-60-22140

Spring

8

07000-15155

O-ring

9

203-60-61130

Cover

10

01010-81225

Bolt

11

01643-31232

Washer

11

203-60-11120

Strainer Assembly

12

203-60-11130

Rod Assembly

13

12R-60-11230

Spring

14

22B-60-11160

Strainer

15

07000-15180

O-ring

16

203-60-11140

Cover

17

01010-81225

Bolt

18

01643-31232

Washer

19

20Y-60-21340

Gasket

20

208-60-71180

Neck

21

01252-70516

Bolt

22

01601-20513

Washer

23

20Y-60-21440

Cap

23

20Y-60-21470

Element

24

07044-12412

Plug

25

07002-12434

O-ring

26

07270-61410

Tube

27

07285-00155

Clip

28

203-00-31120

Decal, Service Instruction, Fuel Level

29

01010-81635

Bolt

30

01643-31645

Washer

31

01010-80825

Bolt

32

01643-30823

Washer

33

203-62-13140

Plate

34

01010-81230

Bolt

35

01643-31232

Washer
