Запчасти Komatsu PC130-8 НАСОС АВТОМАТИЧ. ЗАПРАВКИ ТОПЛИВА W ДРУГОЕ ОБОРУД-Е

1

203-04-K1190

Pump

2

07289-00035

Clamp, Hose

3

07372-21035

Bolt

4

01643-51032

Washer

5

07289-00035

Clamp, Hose

6

07289-00035

Clamp, Hose

7

22D-62-12440

Spacer

8

08193-20010

Clip

9

01010-81060

Bolt

10

01643-31032

Washer

11

203-04-K1180

Cover

12

01010-81020

Bolt

13

01643-31032

Washer

14

203-54-76760

Cap

15

203-04-K1020

Bracket

16

01010-81220

Bolt

17

01643-31232

Washer

|$18

20Y-04-K3081

Switch Assembly

18

Switch

19

20Y-04-K3094

Flange

20

07002-11223

O-Ring

21

07000-13032

O-Ring

|$23

20Y-04-K4081

Box Assembly, Switch, Box

22

20Y-04-K1090

Switch

23

20Y-04-K4090

Switch

24

20Y-04-K4050

Relay

25

01023-10512

Screw

26

20Y-04-K5060

Box

27

20Y-04-K5080

Seat

28

20Y-04-K6020

Gasket

29

20Y-04-K6030

Plate

30

01010-80816

Bolt

31

01643-30823

Washer

32

20Y-00-K2040

Plate

33

01010-81230

Bolt

34

01643-31232

Washer

35

20Y-04-K2450

Valve Assembly

36

20Y-04-K2351

Hose

37

207-04-K1411

Hose

38

01010-81225

Bolt

39

01643-31232

Washer

40

04434-53412

Clip

41

01010-80616

Bolt

42

01643-30623

Washer
