Запчасти Komatsu PC130-8 РУКОЯТЬ, РУКОЯТЬ (.M) T РАБОЧЕЕ ОБОРУДОВАНИЕ

|$1

203-943-K110

Arm Assembly

1

Arm

2

202-973-6320

Bracket, Welded

3

22B-70-K1220

Bracket, Welded

4

22B-70-K1210

Bracket, Welded

5

20E-70-11220

Bracket, Welded

6

20J-70-12180

Seat, Welded

7

22B-70-23630

Bushing

8

203-70-42182

Bushing

9

22B-70-23670

Bushing

10

20T-54-74510

Cap

11

07020-00900

Fitting, Grease

12

07020-00000

Fitting, Grease

13

22B-62-21910

Hose

14

22B-62-21920

Hose

15

07371-30500

Flange, Split

16

01010-80830

Bolt

17

01643-50823

Washer

18

07000-13022

O-Ring

19

203-70-42121

Pin

20

205-70-66580

Plate

21

01010-81230

Bolt

22

01643-31232

Washer

23

07020-00675

Fitting, Grease

24

21Y-70-14830

Spacer, T=1.0mm

25

21Y-70-14840

Spacer, T=2.0mm

26

202-70-52121

Pin

27

21Y-70-14710

Spacer, T=1.0mm

28

205-70-66580

Plate

29

01010-81230

Bolt

30

01643-31232

Washer

31

07145-00070

Seal, Dust

32

21W-70-41440

Seal, Dust
