Запчасти Komatsu PC130-8 ЦИЛИНДР РУКОЯТИ, -ЧАСТИ ТИП, ДЛЯ КЛАПАНА ПЕРЕГРУЗКИ T РАБОЧЕЕ ОБОРУДОВАНИЕ

|1

702-21-18130

Valve, Pilot

|1

702-21-08831

Valve, Pilot

|1

702-21-08830

Valve, Pilot

1

Valve Body

2

Spool

3

702-21-38510

Case

4

702-21-38420

Retainer, 2.0mm

|4

702-21-38550

Retainer, 1.7mm

|4

702-21-38560

Retainer, 2.3mm

5

702-21-38430

Flange

6

702-21-38440

Spring

7

702-21-39720

Spring

|7

702-21-38530

Spring

8

702-21-38460

O-Ring

9

702-21-38470

O-Ring

10

702-21-38480

Plug

11

01252-60620

Bolt, Hexagon Socket Head

|11

01252-30620

Bolt, Hexagon Socket Head

12

01252-60825

Bolt, Hexagon Socket Head

|12

01252-30825

Bolt, Hexagon Socket Head

13

01252-60835

Bolt, Hexagon Socket Head

|13

01252-30835

Bolt, Hexagon Socket Head

14

01641-20608

Washer, Flat

15

07000-12021

O-Ring

16

702-21-39690

Valve

|16

709-74-92810

Valve

17

709-75-92220

Spring

18

700-93-11320

O-Ring

19

700-93-11330

Ring, Back-up

|20

709-70-79800

Valve, Relief

20

Sleeve

21

700-80-64220

Ring, Back-up

22

700-22-11410

O-Ring

23

Seal

24

Poppet

25

Piston

26

Spring

27

Seal

28

07000-13024

O-Ring

29

Poppet

30

O-Ring

31

Plug

32

Nut

33

Nut

34

Spring

35

O-Ring

36

Spacer

37

Seat
