Запчасти Komatsu PC130-8 ЦИЛИНДР РУКОЯТИ, -ЧАСТИ ТИП, ДЛЯ КЛАПАНА ПЕРЕГРУЗКИ T РАБОЧЕЕ ОБОРУДОВАНИЕ

|$0

707-01-0ZG10

Cylinder Assembly

|$1

707-01-0AG20

Cylinder Assembly

1

707-13-11830

Cylinder

2

707-58-75840

Rod

3

22B-70-23620

Bushing

4

07145-00070

Seal, Dust, (Kit : K05)

5

22B-70-23620

Bushing

6

07145-00070

Seal, Dust, (Kit : K05)

7

707-71-32570

Collar

8

707-35-91150

Ring, Back-up, (Kit : K05)

9

07000-15105

O-Ring, (Kit : K05)

10

707-71-70810

Plunger

11

707-71-80230

Plunger

12

04260-00635

Ball, Steel

13

707-71-91270

Cap

14

707-27-11750

Head

15

144-63-94170

Seal, Dust, (Kit : K05)

16

07179-13089

Ring, Snap

17

707-51-75030

Packing, Rod, (Kit : K05)

18

707-51-75650

Ring, Buffer, (Kit : K05)

19

07000-15105

O-Ring, (Kit : K05)

20

707-35-91150

Ring, Back-up, (Kit : K05)

21

707-52-90500

Bushing

22

707-75-75110

Ring, Snap

23

01010-81670

Bolt

24

01643-51645

Washer, Flat

25

707-36-11851

Piston

26

707-44-11250

Ring, Piston

27

707-39-11530

Ring, Wear

28

707-44-11920

Ring

29

01310-01216

Screw

30

07000-15070

O-Ring

31

707-35-90360

Ring, Back-up

32

707-83-13010

Valve

33

07750-01628

Spring

34

07002-12034

O-Ring

35

707-87-14070

Plug

36

707-88-33030

Cap

37

07371-30640

Flange, Split

38

07372-21035

Bolt

39

01643-51032

Washer, Flat

40

07000-13022

O-Ring

41

07378-10500

Head

42

07371-30500

Flange, Split

43

01010-80830

Bolt

44

01643-30823

Washer
