Запчасти Komatsu PC130-8 СТРЕЛА, -ЧАСТИ ТИП T РАБОЧЕЕ ОБОРУДОВАНИЕ

|1

707-01-0AJ50

Cylinder Assembly,RHS

1

707-13-10690

Cylinder

2

21K-70-71320

Bushing

3

07145-00070

Seal, Dust, (Kit : K07)

4

707-27-10750

Head

5

707-52-90470

Bushing

6

707-51-70030

Packing, Rod, (Kit : K07)

7

707-51-70640

Ring, Buffer, (Kit : K07)

8

707-71-32480

Collar

9

07000-15095

O-Ring, (Kit : K07)

10

707-35-91060

Ring, Back-up, (Kit : K07)

11

707-56-70740

Seal, Dust, (Kit : K07)

12

07179-12084

Ring, Snap

13

01010-81465

Bolt

14

705-17-04980

Washer

15

721-58-70500

Rod

16

707-76-80520

Bushing

17

07145-00080

Seal, Dust, (Kit : K07)

18

707-71-70780

Plunger

19

707-36-10760

Piston

20

707-44-10280

Ring, Piston, (Kit : K07)

21

707-39-10550

Ring, Wear, (Kit : K07)

22

707-44-10911

Ring

23

01310-01216

Screw

24

707-34-60030

O-Ring, (Kit : K07)

25

707-35-90730

Ring, Back-up, (Kit : K07)

26

707-75-70110

Ring, Snap

27

707-86-48570

Tube

28

07000-13025

O-Ring, (Kit : K07)

29

01010-80850

Bolt

30

01643-80823

Washer

31

707-88-21720

Band

32

707-88-25110

Bracket

33

07372-21035

Bolt

34

01643-51032

Washer, Flat

35

01010-81030

Bolt

36

01643-31032

Washer

37

02896-11012

O-Ring, (Kit : K07)

|38

707-79-90190

Valve Subassembly

38

02896-11015

O-Ring

39

707-86-55630

Tube

40

01010-80830

Bolt

41

01643-30823

Washer

42

07000-13025

O-Ring

43

702-21-08371

Valve Assembly, Pilot

|43

702-21-08370

Valve Assembly, Pilot

44

07000-13025

O-Ring, (Kit : K07)

45

01010-80850

Bolt

46

01643-30823

Washer

47

01010-80860

Bolt

48

01010-81030

Bolt

49

01643-31032

Washer
