Запчасти Komatsu PC130-8 МЕХАНИЗМ ПОВОРОТА N ПОВОРОТН. КРУГ И ITS КОМПОНЕНТЫ

|$0

203-26-81000

Swing Machinery Assembly

1

203-26-81111

Case

2

22B-26-21130

Gear, Ring

3

203-26-61120

Carrier

4

203-26-61130

Carrier

5

203-26-61220

Shaft

6

203-26-61150

Gear

7

203-26-61160

Gear

8

203-26-61170

Gear

9

203-26-61180

Gear

10

201-26-62240

Shaft

11

203-26-61250

Shaft

12

201-26-62270

Bearing

13

203-26-61270

Bearing

14

20S-26-71160

Washer

15

09233-12920

Washer, Thrust

16

20S-26-71250

Pin

17

20S-26-71190

Ring, Snap

18

04064-05520

Ring, Snap, for Shaft Side

19

203-26-61280

Spacer

20

203-26-61391

Spacer

21

203-26-61310

Collar

22

201-26-62330

Bearing

23

203-26-61320

Bearing

24

203-26-61340

Collar

25

07000-12080

O-Ring

26

07012-00145

Seal, Oil

27

203-26-61360

O-Ring

28

203-26-13111

Elbow

29

07002-12434

O-Ring

30

07040-11612

Plug

31

07002-11623

O-Ring

32

07049-01620

Plug, Cork

33

04020-01638

Pin, Dowel

34

07049-02025

Plug, Cork
