Запчасти Komatsu PC130-8 КАБИНА, -АКТУАТОР, ОТВАЛ СПЕЦ-ЯIFICATION K OPERATORґS ОБСТАНОВКА И СИСТЕМА УПРАВЛЕНИЯ

|$0

20Y-53-13631

Cover Assembly

1

Cover

2

22U-43-22340

Puller

3

08041-01000

Fuse, 10Amp.

4

08041-02000

Fuse, 20Amp.

5

08041-03000

Fuse, 30Amp.

6

20Y-53-12371

Cover

7

208-53-12290

Hook

8

01580-10403

Nut

9

01640-20408

Washer, Flat

10

01601-20410

Washer, Spring

11

01435-40616

Bolt

12

20Y-53-12310

Collar

13

208-979-7560

Grille

14

20Y-53-12381

Cover

15

09452-14503

Catcher, Magnet

16

01370-10308

Screw

17

20Y-53-12391

Cover

18

208-53-12410

Plate

19

01370-20308

Screw

20

208-53-12320

Pin

21

208-53-12330

Ring

22

01435-40616

Bolt

23

20Y-53-12310

Collar

24

20Y-53-12931

Cover

25

01435-40620

Bolt

26

20Y-53-12310

Collar

27

23D-950-4450

Button

28

20Y-53-12860

Spacer

29

22U-06-22251

Converter

30

01435-00610

Bolt

31

198-Z11-2640

Socket Assembly

32

01010-81245

Bolt

33

01643-31232

Washer

34

01010-D1650

Bolt

35

01643-31645

Washer

36

20Y-53-18221

Bracket

37

01435-00612

Bolt
