Запчасти Komatsu PC130-8 ЦИЛИНДР СТРЕЛЫ, ЧАС. СИСТ. СМАЗКИ ТИП, (/) ЦИЛИНДР СТРЕЛЫ, ЧАС. СИСТ. СМАЗКИ ТИП

|1

707-01-0AJ80

Cylinder Assembly

1

707-13-10670

Cylinder

2

721-58-70490

Rod

3

707-76-70230

Bushing

4

07145-00070

Seal, Dust, (Kit : K03)

5

07020-00000

Fitting, Grease

6

707-76-70230

Bushing

7

07145-00070

Seal, Dust, (Kit : K03)

8

707-27-10750

Head, Cylinder

9

144-63-95170

Seal, Dust, (Kit : K03)

10

07179-12084

Ring, Snap

11

707-51-70030

Packing, Rod, (Kit : K03)

12

707-51-70650

Ring, Buffer, (Kit : K03)

13

707-52-90471

Bushing

14

707-75-70110

Ring, Snap

15

07000-15095

O-ring, (Kit : K03)

16

707-35-91060

Ring, Back-up, (Kit : K03)

17

01010-81465

Bolt

18

705-17-04980

Washer

19

707-36-10760

Piston

20

707-44-10250

Ring, Piston, (Kit : K03)

21

707-39-10550

Ring, Wear, (Kit : K03)

22

707-44-10911

Ring

23

01310-01216

Screw

24

707-34-60030

O-ring, (Kit : K03)

25

707-35-90730

Ring, Back-up, (Kit : K03)

26

707-86-48490

Tube

27

02896-11012

O-ring, (Kit : K03)

28

707-86-55580

Tube

29

02896-11015

O-ring, (Kit : K03)

30

01010-80850

Bolt

31

01643-30823

Washer

32

07000-13025

O-ring, (Kit : K03)

33

707-88-25110

Bracket

34

707-88-21720

Band

35

07372-21035

Bolt

36

01643-51032

Washer

37

01010-81030

Bolt

38

01643-31032

Washer
