Запчасти Komatsu PC130-8 ЦИЛИНДР СТРЕЛЫ, ДЛЯ КЛАПАНА ПЕРЕГРУЗКИ(№8-) ЦИЛИНДР СТРЕЛЫ, ДЛЯ КЛАПАНА ПЕРЕГРУЗКИ

|$0

702-21-08810

Valve Assembly, Pilot

1

Valve Body

2

Spool

3

702-21-38671

Plate

4

Retainer, 2.0mm

|$5

Retainer, 1.7mm

|$6

Retainer, 2.3mm

5

702-21-38741

Plate

6

702-21-38440

Spring

7

702-21-38530

Spring

8

702-21-38460

O-ring

9

702-21-38470

O-ring

10

702-21-38480

Plug

11

01252-60625

Bolt, Hexagon Socket Head

12

01252-60840

Bolt, Hexagon Socket Head

13

01252-60835

Bolt, Hexagon Socket Head

14

01641-20608

Washer, Flat

15

07000-12021

O-ring

16

709-74-92810

Valve

17

709-75-92220

Spring

18

700-93-11320

O-ring

19

700-93-11330

Ring, Back-up

20

702-21-55620

Plug

21

07002-11423

O-ring

|$24

709-70-79800

Valve, Relief

22

Sleeve

23

700-80-64220

Ring, Back-up

24

700-22-11410

O-ring

25

Seal

26

Poppet

27

Piston

28

Spring

29

Seal

30

07000-13024

O-ring

31

Poppet

32

O-ring

33

Plug

34

Nut

35

Nut

36

Spring

37

O-ring

38

Spacer

39

Seat
