/ / / / / / / КАБИНА, -АКТУАТОР, ОТВАЛ СПЕЦ-ЯIFICATION(№8-)
Запчасти Komatsu PC130-8 КАБИНА, -АКТУАТОР, ОТВАЛ СПЕЦ-ЯIFICATION(№8-) КАБИНА, -АКТУАТОР, ОТВАЛ СПЕЦ-ЯIFICATION
2
4
6
7
8
11
9
11
9
12
18
14
13
18
15
18
17
19
23
22
21
25
24
25
24
26
10
10
16
3
30
29
28
29
29
31
32
32
35
34
33
33
33
37
36
38
39
39
44
45
46
48
49
43
42
41
40
47
50
5
1
27
27
20
1
20Y-43-42313
Frame
2
01010-D1230
Bolt
3
01643-71232
Washer
4
20Y-43-41631
Sheet
5
22U-43-23251
Sheet
6
22U-43-23290
Clip
7
20Y-43-41323
Cover
8
20Y-43-41661
Sheet
9
01010-80616
Bolt
10
01643-30623
Washer, Flat
11
20Y-43-41290
Collar
12
20Y-43-41332
Cover
13
01245-00616
Screw, Hexagon Socket Head
14
01643-70623
Washer
15
01010-80616
Bolt
16
01643-30623
Washer, Flat
17
01435-00612
Bolt
18
20Y-43-41290
Collar
19
20Y-43-41353
Cover
20
20Y-43-42120
Bracket
21
01245-00620
Screw, Hexagon Socket Head
22
01643-70623
Washer
23
20Y-43-41290
Collar
24
01245-00616
Screw, Hexagon Socket Head
25
01643-70623
Washer
26
09415-02512
Cap
27
08086-20000
Switch, Starting
28
20Y-43-41740
Plate
29
20Y-43-41750
Washer
30
20Y-43-41790
Washer
31
20Y-43-41671
Sheet
32
08034-20519
Band
33
22U-06-22380
Potentiometer
34
22U-06-22460
Spring
35
20Y-43-41780
Knob
36
20Y-06-42110
Switch, Swing Lock
37
20Y-06-42121
Switch, Light
38
20Y-06-42130
Switch
39
20Y-06-42190
Cover
40
20Y-06-K8130
Wire Harness
41
08034-20414
Band
42
01023-10508
Screw
43
01601-20513
Washer, Spring
44
22U-43-23260
Clip
45
04434-51710
Clip
46
01010-81016
Bolt
47
01643-31032
Washer
48
04434-51410
Clip
49
01010-81016
Bolt
50
01643-31032
Washer
