Запчасти Komatsu PC130-8 КАБИНА, -АКТУАТОР(№8-8) КАБИНА, -АКТУАТОР

1

203-06-11260

Bracket

2

08088-30000

Switch, Battery Relay

3

01010-80830

Bolt

4

01643-30823

Washer

5

08038-00519

Cap, Terminal

6

08038-06031

Cap, Terminal

7

08038-00035

Cap, Terminal

8

600-815-8941

Relay, Safety

9

01010-80816

Bolt

10

01643-30823

Washer

11

01010-80816

Bolt

12

01643-30823

Washer

13

600-815-2170

Switch

14

01010-80616

Bolt

15

01643-30623

Washer, Flat

16

08038-00519

Cap, Terminal

17

08038-06031

Cap, Terminal

18

08034-20536

Band

19

01010-81020

Bolt

20

01643-31032

Washer

21

203-06-11370

Sheet

22

20T-54-74510

Cap

23

203-06-11340

Wire Harness

24

203-06-11240

Cable

25

203-06-11710

Wire Harness

26

08028-20000

Diode

27

08041-00500

Fuse, 5Amp.

28

08041-01000

Fuse, 10Amp.

29

08041-02000

Fuse, 20Amp.

30

08041-03000

Fuse, 30Amp.

31

19M-06-37172

Resistor

32

20Y-06-31660

Fusible Link, 30Amp.

33

20U-06-11270

Fusible Link, 65Amp.

34

HM6400-0012

Connector, Black

35

HM6400-0013

Connector, Green

36

HM6440-0129

Connector, Pink

37

HM6400-0016

Connector, Orange

38

08028-CB050

Cable, Ground
