Запчасти Komatsu PC130-8 МОТОР ХОДА И КОНЕЧНАЯ ПЕРЕДАЧА, ВНУТР. ЧАСТИ, МОТОР ХОДА (/) (№8-) МОТОР ХОДА И КОНЕЧНАЯ ПЕРЕДАЧА

|$0

22B-60-22110

Motor Assembly

|$1

TZ600D300000-A

Valve Assembly, Relief

|$2

TZ600D310000-A

Valve Assembly, Relief

1

Seat, Valve

2

Valve

3

Sleeve

4

Collar

5

Plug

6

Spring

7

TZJB2401-P10A

O-ring, (Kit : K01)

8

TZJB2407T2P10A

Ring, Back-up, (Kit : K01)

9

07000-12014

O-ring, (Kit : K01)

10

TZJB2407T2-P14

Ring, (Kit : K01)

11

07000-12011

O-ring, (Kit : K01)

12

07000-12018

O-ring, (Kit : K01)

13

Shim

13

TZ600D400001-B

Valve Assembly, Control

13

TZ600D410001-B

Flange Assembly

13

TZ600D410101-B

Flange Kit

13

TZ600D415001-B

Spool Assembly

14

Spool

15

Plug

16

Valve

17

Spring

18

O-ring

19

Flange

20

Plug

21

TZ600D4052-01

Washer

22

TZ100A2055-00

Spring

23

TZS0506

Orifice

24

07000-13032

O-ring, (Kit : K01)

25

TZ200C2021-01

Plug

26

04260-00793

Ball

27

TZGDL1-16-S

Plug, Hexagon Head

28

TZ610B2021-00

Plug

29

07000-11008

O-ring, (Kit : K01)

30

07000-12018

O-ring, (Kit : K01)

31

TZ600D4069-00

Spool

32

TZ420B2089-01

Spring

33

TZS0505

Orifice

34

TZ976B2079-00

Filter

35

04260-00476

Ball

36

TZ571B2079-00

Plug

37

TZ200C2021-00

Plug

38

TZ600D4081-00

Piston

39

07000-12014

O-ring, (Kit : K01)

40

TZS0545

Orifice

41

TZGM1-4-G-S

Plug

42

TZGM1-8-S

Plug, Hexagon Head

43

TZ850A0006-00

Plate, Name

44

TZJB1354-4-10

Pin

45

01252-31230

Bolt
