Запчасти Komatsu PC130-8 ЦИЛИНДР РУКОЯТИ(№8-) ЦИЛИНДР РУКОЯТИ

Схема запчастей Komatsu PC130-8 - ЦИЛИНДР РУКОЯТИ(№8-) ЦИЛИНДР РУКОЯТИ
32
33
34
31
30
29
35
31
28
27
26
25
10
6
5
13
12
11
2
24
23
16
15
20
19
6
8
4
28
27
18
17
21
14
8
9
7
4
3
1
45
36
40
38
39
42
41
43
44
46
47
22
37

Артикул

Название

Примечание

Количество

|$0

707-01-0AG20

Cylinder Assembly

1

707-13-11830

Cylinder

2

707-58-75840

Rod, Piston

3

22B-70-23620

Bushing

4

07145-00070

Seal, Dust, (Kit : K05)

5

22B-70-23620

Bushing

6

07145-00070

Seal, Dust, (Kit : K05)

7

707-71-32570

Collar

8

707-35-91150

Ring, Back-up, (Kit : K05)

9

07000-15105

O-ring, (Kit : K05)

10

707-71-70810

Plunger

11

707-71-80230

Plunger

12

04260-00635

Ball, Steel

13

707-71-91270

Cap

14

707-27-11750

Head, Cylinder

15

707-56-75740

Seal, Dust, (Kit : K05)

16

07179-13089

Ring, Snap

17

707-51-75030

Packing, Rod, (Kit : K05)

18

707-51-75650

Ring, Buffer, (Kit : K05)

19

07000-15105

O-ring, (Kit : K05)

20

707-35-91150

Ring, Back-up, (Kit : K05)

21

707-52-90501

Bushing

22

707-75-75110

Ring, Snap

23

01010-81670

Bolt

24

01643-51645

Washer

25

707-36-11851

Piston

26

707-44-11250

Ring, Piston, (Kit : K05)

27

707-39-11530

Ring, Wear, (Kit : K05)

28

707-44-11920

Ring

29

01310-01216

Screw

30

07000-15070

O-ring, (Kit : K05)

31

707-35-90360

Ring, Back-up, (Kit : K05)

32

707-83-13010

Valve

33

07750-01628

Spring

34

07002-12034

O-ring, (Kit : K05)

35

707-87-14070

Plug

36

707-86-55540

Tube

37

02896-11015

O-ring, (Kit : K05)

38

01010-80850

Bolt

39

01643-30823

Washer

40

07000-13025

O-ring, (Kit : K05)

41

707-88-50490

Bracket

42

707-88-21680

Band

43

07372-21035

Bolt

44

01643-51032

Washer

45

07283-32236

Clip, Pipe

46

01597-01009

Nut

47

01643-31032

Washer

Выбрано товаров: 48
