Запчасти Komatsu PC130-8 ЦИЛИНДР СТРЕЛЫ, ЛЕВ. (№8-8) ЦИЛИНДР СТРЕЛЫ, ЧАС. СИСТ. СМАЗКИ ТИП, С СТРЕЛА И РУКОЯТЬ ANTI-DROP КЛАПАН

|$0

707-01-0AK20

Cylinder Assembly

1

707-13-10680

Cylinder

2

721-58-70490

Rod, Piston

3

707-76-70230

Bushing

4

07145-00070

Seal, Dust, (Kit : K04)

5

07020-00000

Fitting, Grease

6

707-76-70230

Bushing

7

07145-00070

Seal, Dust, (Kit : K04)

8

707-27-10750

Head, Cylinder

9

707-56-70740

Seal, Dust, (Kit : K04)

10

07179-12084

Ring, Snap

11

707-51-70030

Packing, Rod, (Kit : K04)

12

707-51-70650

Ring, Buffer, (Kit : K04)

13

707-52-90471

Bushing

14

707-75-70110

Ring, Snap

15

07000-15095

O-ring, (Kit : K04)

16

707-35-91060

Ring, Back-up, (Kit : K04)

17

01010-81465

Bolt

18

705-17-04980

Washer

19

707-36-10760

Piston

20

707-44-10250

Ring, Piston, (Kit : K04)

21

707-39-10550

Ring, Wear, (Kit : K04)

22

707-44-10911

Ring

23

01310-01216

Screw

24

707-34-60030

O-ring, (Kit : K04)

25

707-35-90730

Ring, Back-up, (Kit : K04)

26

707-86-48520

Tube

27

01010-80850

Bolt

28

01643-30823

Washer

29

07000-13025

O-ring, (Kit : K04)

30

707-88-25460

Bracket

31

707-88-21720

Band

32

07372-21035

Bolt

33

01643-51032

Washer

34

01010-81030

Bolt

35

01643-31032

Washer

36

02896-11012

O-ring, (Kit : K04)
