Запчасти Komatsu PC130-7K ОСНОВН. КЛАПАН (7-КЛАПАН) (/) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|1

723-57-11700

CONTROL VALVE

|1

BLOCK GROUP

1

BLOCK

2

144-14-54610

O-RING

3

723-56-31730

O-RING

4

702-75-11520

O-RING

5

07000-11008

O-RING

6

SLEEVE

7

PISTON

8

723-36-15340

SPRING

9

723-56-31890

SLEEVE

10

PISTON

11

723-36-15240

SPRING

12

723-36-15250

CASE

13

07000-13042

O-RING

14

01252-60820

BOLT

|15

COVER GROUP

15

COVER

16

723-50-11311

PLUG

17

07000-11004

O-RING

18

07001-01004

RING

19

07002-11423

O-RING

20

723-26-15190

PLUG

21

07000-11007

O-RING

22

07001-01007

RING,BACK-UP

23

07000-11009

O-RING

24

07001-01009

RING,BACK-UP

25

708-8E-16160

PLUG

26

07002-11023

O-RING

27

07040-11409

PLUG

28

07002-11423

O-RING

29

723-50-11170

STUD

30

01643-31232

WASHER

31

01580-11210

NUT

32

01252-60850

BOLT
