Запчасти Komatsu PC130-7K ЦИЛИНДР РУКОЯТИ(С КЛАПАН ПЕРЕГРУЗКИ) (ВНУТР. ЧАСТИ) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

G1

707-01-XU530

CYLINDER GROUP,ARM (FINAL COATING)

|1

707-01-0F030

CYLINDER ASS'Y,ARM

1

707-13-11640

CYLINDER,ARM

2

707-76-70240

BUSHING

3

07145-00070

SEAL,DUST (KIT)

4

707-27-11971

HEAD,CYLINDER

5

707-52-90500

BUSHING

6

707-51-75030

PACKING,ROD (KIT)

7

707-51-75640

RING,BUFFER (KIT)

8

707-71-32530

COLLAR

9

07000-15105

O-RING (KIT)

10

707-35-91150

RING,BACK-UP (KIT)

11

07000-15105

O-RING (KIT)

12

707-35-91150

RING,BACK-UP (KIT)

13

144-63-94170

SEAL,DUST (KIT)

14

07179-13089

RING,SNAP

15

01010-81670

BOLT

16

01643-51645

WASHER

17

707-58-75670

ROD

18

707-71-80230

PLUNGER

19

04260-00635

BALL

20

707-71-91270

CAP

21

707-76-70240

BUSHING

22

07145-00070

SEAL,DUST (KIT)

23

707-71-60870

PLUNGER

24

707-36-11851

PISTON

25

707-44-11280

RING,PISTON (KIT)

26

707-39-11530

RING,WEAR (KIT)

27

707-44-11920

RING

28

01310-01216

SCREW

29

07000-15070

O-RING (KIT)

30

707-35-90360

RING,BACK-UP (KIT)

31

707-83-13010

VALVE

32

07750-01628

SPRING

33

707-87-14070

PLUG

34

07002-12034

O-RING (KIT)

35

707-87-13570

ELBOW

36

07000-13025

O-RING (KIT)

37

01435-00855

BOLT

38

707-88-21680

BAND

39

707-88-25080

BRACKET

40

01435-01030

BOLT

|K

707-99-44340

SERVICE KIT
