Запчасти Komatsu PC130-7K ЦИЛИНДР СТРЕЛЫ(ВНУТР. ЧАСТИ) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

G1

707-01-XT200

BOOM CYLINDER GROUP,L.H. (FINAL COATING)

G2

707-01-XT210

BOOM CYLINDER GROUP,R.H. (FINAL COATING)

|1

707-01-0G230

CYLINDER ASS'Y,BOOM

1

707-13-10570

CYLINDER

2

707-76-70230

BUSHING

3

07145-00070

SEAL,DUST (KIT)

4

07020-00000

FITTING,GREASE

5

707-27-10971

HEAD,CYLINDER

6

707-52-90470

BUSHING

7

707-51-70030

PACKING,ROD (KIT)

8

707-51-70640

RING,BUFFER (KIT)

9

07000-15095

O-RING (KIT)

10

707-35-91060

RING,BACK-UP (KIT)

11

144-63-95170

SEAL,DUST (KIT)

12

07179-12084

RING,SNAP

13

01010-81465

BOLT

14

705-17-04980

WASHER

15

203-63-55521

ROD

16

707-76-70230

BUSHING

17

07145-00070

SEAL,DUST (KIT)

18

707-36-10760

PISTON

19

707-44-10280

RING,PISTON (KIT)

20

707-39-10550

RING,WEAR (KIT)

21

707-44-10911

RING

22

01310-01216

SCREW

23

707-34-60030

O-RING (KIT)

24

707-35-90730

RING,BACK-UP (KIT)

25

707-86-47930

TUBE,L.H.

|25

707-86-47940

TUBE,R.H.

26

07000-13025

O-RING (KIT)

27

01010-80850

BOLT

28

01643-50823

WASHER

29

707-88-21720

BAND

30

707-88-25460

BRACKET

31

01010-81035

BOLT

32

01643-51032

WASHER

33

01010-81030

BOLT

34

01643-31032

WASHER

K

707-99-37300

SERVICE KIT,BOOM CYLINDER
