Запчасти Komatsu PC130-6K ОСНОВН. НАСОС (/9) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|1

708-1L-00071

PUMP ASS'Y

|1

708-1L-03400

SERVO VALVE ASS'Y

1

708-2L-25382

PLUG

2

07000-02010

O-RING

3

04065-01610

RING

4

708-2L-25513

SPOOL

5

708-2L-25611

PISTON

6

708-2L-25521

SLEEVE

7

708-2L-25531

PLUG

8

07002-12034

O-RING

9

708-2L-25542

SEAT

10

708-2L-25551

SPRING

11

708-2L-25640

SEAT

12

708-2L-25621

PLUG

13

07001-02012

RING,BACK-UP

14

07000-12012

O-RING

15

01583-12012

NUT

|16

708-1L-03910

BLOCK ASS'Y

16

708-1L-25130

BLOCK

17

706-86-51180

PLUG

18

708-1L-25410

SCREW

19

01583-52414

NUT

20

07002-12434

O-RING

21

708-1L-25420

SPOOL

22

708-1L-25430

PLUG

23

708-1L-25440

SPRING

24

708-1L-25450

SPRING

25

708-1L-25460

POPPET

26

708-1L-25470

ROD

27

708-1L-25480

SEAT

28

708-1L-25490

PLUG

29

07002-11423

O-RING

30

07000-02014

O-RING

31

07000-B2010

O-RING

32

01252-30850

BOLT

33

708-2L-25480

FILTER

34

708-2L-25490

O-RING

35

708-8E-16150

PLUG

36

07002-11023

O-RING

37

07000-02110

O-RING
