Запчасти Komatsu PC130-6G ХОД MTOR (КОНЕЧНАЯ ПЕРЕДАЧА В СБОРЕ) (GM8VL ТИП)(№77-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|1

203-60-63102

TRAVEL MOTOR ASS'Y

|1

TZ266B1000-01

FINAL DRIVE ASS'Y

1

TZ266B1001-00

HUB

|2

TZ263B1102-01

SPINDLE KIT

2

TZ263B1132-05

SPINDLE ASS'Y

|2

SPINDLE

|2

FLANGE

3

TZ200B1019-03

BOLT,REAMER

4

TZES100-250-A

SEAL,FLOATING (K1)

5

TZ200B1021-00

BEARING

|6

TZ263B1104-00

RV GEAR ASS'Y

6

TZ263B1204-00

RV GEAR KIT

|6

GEAR

|6

GEAR

7

TZ200B1009-01

SHAFT,CRANK

8

TZ200B1022-00

BEARING

9

TZ200B1023-00

BEARING

10

TZ150A1020-00

SNAP RING KIT (12 KINDS)

11

TZ266B1107-00

SPUR GEAR KIT (3 PIECES)

|11

GEAR

12

TZ200B1014-01

PIECE,DISTANCE

13

04064-03515

RING,SNAP

14

TZ266B1006-00

GEAR,INPUT

15

04260-00952

BALL,SNAP

16

TZ800A1015-00

JOINT

17

TZ225B1017-00

PIN

18

TZ266B1008-00

COVER

19

TZGM1-2

PLUG

20

TZARP568-378-7

O-RING (K1)

21

TZJB1176M12-32

BOLT

22

07000-11007

O-RING (K1)

23

TZJW1516-G37-7

O-RING (K1)

K1

TZ266B9000-00

SERVICE KIT

|K

07000-11007

O-RING

|K

TZARP568-378-7

O-RING,BACK-UP

|K

TZJW1516-G37-7

O-RING

|K

TZES100-250-A

SEAL,BACK-UP

|K

TZ15Z-22-42-10

SEAL,OIL

|K

TZ266B2035-00

O-RING

|K

TZJB2401-P26-9

O-RING

|K

07000-12016

O-RING

|K

07000-12018

O-RING

|K

TZ266B2039-00

O-RING

|K

07002-02034

O-RING

|K

07000-12011

O-RING

|K

07000-12014

O-RING,FLOATING

|K

07000-12020

O-RING

|K

TZJB2407T2-P14

RING

|K

TZJB2407T3-P20

RING
