Запчасти Komatsu PC130-6E0-T2 ОСНОВН. КЛАПАН (8-КЛАПАН) (/) (С ОТВАЛ) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|1

723-58-12505

CONTROL VALVE

|1

723-58-12504

CONTROL VALVE

|1

723-58-12503

CONTROL VALVE

|1

723-58-12502

CONTROL VALVE

|1

723-58-12501

CONTROL VALVE

|1

723-58-12500

CONTROL VALVE

|1

723-58-11503

CONTROL VALVE

|1

723-58-11502

CONTROL VALVE

|1

723-58-11501

CONTROL VALVE

|1

723-58-11500

CONTROL VALVE

|1

723-51-01700

VALVE ASS'Y

|1

723-51-01202

VALVE ASS'Y

|1

723-51-01201

VALVE ASS'Y

|1

723-51-01200

VALVE ASS'Y

1

BLOCK,VALVE

2

144-14-54610

O-RING

3

723-56-31720

O-RING

4

723-56-31730

O-RING

5

702-75-11520

O-RING

6

07000-11008

O-RING

7

SPOOL

|7

SPOOL

|7

SPOOL

8

PLUG

9

07002-11223

O-RING

10

723-56-31210

RETAINER

11

723-36-14110

SPRING

12

723-56-31510

CASE

13

702-21-55450

O-RING

14

01252-60630

BOLT

15

VALVE

16

723-56-41710

SPRING

17

723-26-15230

PLUG

18

07002-12434

O-RING

19

VALVE

|19

VALVE

20

723-56-41750

SPRING
