Запчасти Komatsu PC130-6 ОСНОВН. КЛАПАН (8-КЛАПАН) (9/) (С ОТВАЛ)(№-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ
№
Артикул
Название
Примечание
Количество
|$11
723-58-12506
CONTROL VALVE
|$12
723-58-12505
CONTROL VALVE
|$13
723-58-12504
CONTROL VALVE
|$14
723-58-12503
CONTROL VALVE
|$15
723-58-12502
CONTROL VALVE
|$16
723-58-12501
CONTROL VALVE
|$17
723-58-12500
CONTROL VALVE
|$18
723-58-11503
CONTROL VALVE
|$19
723-58-11502
CONTROL VALVE
|$20
723-58-11501
CONTROL VALVE
|$21
723-58-11500
CONTROL VALVE
|$23
723-50-51400
VALVE ASS'Y
|$24
723-50-51300
VALVE ASS'Y
|$25
723-50-51100
VALVE ASS'Y
1
BLOCK
2
SPOOL
2
SPOOL
2
SPOOL
3
723-50-51230
SPRING
3
723-50-51130
SPRING
4
723-50-51140
PLUG
5
07002-11623
O-RING
6
723-50-51150
FLANGE
7
07000-12011
O-RING
8
07000-11007
O-RING
9
01252-60620
BOLT
10
BALL
11
723-50-51160
PLUG
12
07000-11003
O-RING
13
07002-10823
O-RING
14
SCREW
15
07000-11008
O-RING
|$44
723-50-52200
VALVE ASS'Y
|$45
723-50-52100
VALVE ASS'Y
16
BLOCK
17
SPOOL
18
723-50-52130
RETAINER
19
723-50-52150
SPRING
19
723-50-52140
SPRING
20
723-56-31630
PLUG
21
07002-11623
O-RING
22
BALL
23
723-50-51160
PLUG
24
07000-11003
O-RING
25
07002-10823
O-RING
26
723-56-41620
ORIFICE
27
723-11-18190
PLUG
28
07002-11023
O-RING
29
SCREW
30
07000-11008
O-RING
31
07000-11007
O-RING
|$63
723-50-54100
VALVE ASS'Y
32
723-50-54110
BLOCK
33
723-56-31610
VALVE
34
723-56-31620
SPRING
35
723-56-31630
PLUG
36
07002-11623
O-RING
37
723-11-18190
PLUG
38
07002-11023
O-RING
39
07000-11009
O-RING
40
708-2L-25490
O-RING
Выбрано товаров: 61
