Запчасти Komatsu PC130-6 ОСНОВН. КЛАПАН (-АКТУАТОР) (/)(№-999) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|1

723-37-10401

CONTROL VALVE

|1

723-37-10400

CONTROL VALVE

1

723-36-41110

VALVE

2

723-36-41121

VALVE

|3

723-36-42401

VALVE ASS'Y

3

PISTON SUB ASS'Y

4

SLEEVE

5

SPRING

6

700-80-61260

O-RING

7

700-80-61430

RING

8

07002-13034

O-RING

|9

723-36-41500

VALVE ASS'Y

9

PISTON SUB ASS'Y

10

SLEEVE

11

SPRING

12

700-80-61260

O-RING

13

700-80-61430

RING

14

07002-13034

O-RING

|15

723-36-40400

VALVE ASS'Y

15

PISTON SUB ASS'Y

16

SLEEVE

17

SPRING

18

700-80-61260

O-RING

19

700-80-61430

RING

20

07002-13034

O-RING

|21

723-36-41400

VALVE ASS'Y

21

PISTON SUB ASS'Y

22

SLEEVE

23

SPRING

24

700-80-61260

O-RING

25

700-80-61430

RING

26

07002-13034

O-RING

|27

723-36-43301

VALVE ASS'Y

27

PISTON

28

SEAL

29

SLEEVE

30

SPRING

31

700-80-61260

O-RING

32

700-80-61430

RING

33

07002-13034

O-RING

|34

723-36-43400

VALVE ASS'Y

34

PISTON SUB ASS'Y

35

SLEEVE

36

SPRING

37

700-80-61260

O-RING

38

700-80-61430

RING

39

07002-13034

O-RING
