Запчасти Komatsu PC130-6 ОСНОВН. КЛАПАН (9-КЛАПАН) (/)(№-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

Схема запчастей Komatsu PC130-6 - ОСНОВН. КЛАПАН (9-КЛАПАН) (/)(№-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ
1
2
3
4
5
6
7
8
8
9
9
9
10
11
12
13
14
15
16
17
17
18
18
19
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35

Артикул

Название

Примечание

Количество

|1

723-59-12305

CONTROL VALVE

|1

723-59-12304

CONTROL VALVE

|1

723-59-12303

CONTROL VALVE

|1

723-59-12302

CONTROL VALVE

|1

723-59-12301

CONTROL VALVE

|1

723-59-12300

CONTROL VALVE

|1

723-59-11303

CONTROL VALVE

|1

723-59-11302

CONTROL VALVE

|1

723-59-11301

CONTROL VALVE

|1

723-59-11300

CONTROL VALVE

|1

723-51-01301

VALVE ASS'Y

|1

723-51-01300

VALVE ASS'Y

|1

723-50-42103

VALVE ASS'Y

|1

723-50-42100

VALVE ASS'Y

1

SLEEVE

|1

SLEEVE

2

07000-13024

O-RING

3

SEAT

|3

SEAT

4

SEAL

|4

SEAL

5

POPPET

6

SPRING

7

PLUG

|7

PLUG

8

O-RING

9

RING

10

SCREW

11

O-RING

12

RING,BACK-UP

13

NUT

|13

NUT

14

PLATE

|14

PLATE

15

NUT

16

CAP

17

723-56-31640

PLUG

18

07002-11623

O-RING

19

07000-11008

O-RING

|20

709-70-74600

VALVE ASS'Y,SUCTION AND SAFETY

20

SLEEVE

21

SLEEVE

22

POPPET

23

PISTON

24

PLUG

25

POPPET

26

SCREW

27

SPRING

28

SPRING

29

SPRING

30

SEAL

31

SEAL

32

709-25-11390

O-RING

33

O-RING

34

O-RING

35

NUT

Выбрано товаров: 56
