Запчасти Komatsu PC130-6 ОСНОВН. КЛАПАН (9-КЛАПАН) (/)(№-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ
№
Артикул
Название
Примечание
Количество
|1
723-59-12305
CONTROL VALVE
|1
723-59-12304
CONTROL VALVE
|1
723-59-12303
CONTROL VALVE
|1
723-59-12302
CONTROL VALVE
|1
723-59-12301
CONTROL VALVE
|1
723-59-12300
CONTROL VALVE
|1
723-59-11303
CONTROL VALVE
|1
723-59-11302
CONTROL VALVE
|1
723-59-11301
CONTROL VALVE
|1
723-59-11300
CONTROL VALVE
|1
723-51-01700
VALVE ASS'Y
|1
723-51-01202
VALVE ASS'Y
|1
723-51-01201
VALVE ASS'Y
|1
723-51-01200
VALVE ASS'Y
|1
723-50-42103
VALVE ASS'Y
|1
723-50-42100
VALVE ASS'Y
1
SLEEVE
|1
SLEEVE
2
07000-13024
O-RING
3
SEAT
|3
SEAT
4
SEAL
|4
SEAL
5
POPPET
6
SPRING
7
PLUG
|7
PLUG
8
O-RING
9
RING
10
SCREW
11
O-RING
12
RING,BACK-UP
13
NUT
|13
NUT
14
PLATE
|14
PLATE
15
NUT
16
CAP
17
723-56-31640
PLUG
18
07002-11623
O-RING
19
07000-11008
O-RING
|20
709-70-74600
VALVE ASS'Y,SUCTION AND SAFETY
20
SLEEVE
21
SLEEVE
22
POPPET
23
PISTON
24
PLUG
25
POPPET
26
SCREW
27
SPRING
28
SPRING
29
SPRING
30
SEAL
31
SEAL
32
709-25-11390
O-RING
33
O-RING
34
O-RING
35
NUT
Выбрано товаров: 58
