Запчасти Komatsu PC130-5K ЦИЛИНДР КОВША РАБОЧЕЕ ОБОРУДОВАНИЕ (ЭКСКАВАТ.)

|1

203-63-K1901

CYLINDER ASS'Y,BUCKET (WITH TUBE)

|1

203-63-K1911

CYLINDER ASS'Y,BUCKET

1

203-63-K2610

CYLINDER

2

707-76-70230

BUSHING

3

07145-00070

SEAL,DUST

4

203-63-K2370

FITTING,GREASE

5

203-63-K2280

HEAD,CYLINDER

6

707-52-90450

BUSHING

7

707-51-70030

PACKING,ROD

8

203-63-K2350

RING,BACK-UP

9

707-51-70630

RING,BUFFER

10

203-63-K2320

O-RING

11

203-63-K2330

RING,BACK-UP

12

144-63-95170

SEAL,DUST

13

203-63-K2360

RING,SNAP

14

203-63-K2380

BOLT

15

203-63-K2620

ROD,PISTON

16

707-76-70370

BUSHING

17

21K-70-12180

SEAL,DUST

18

203-63-K2370

FITTING,GREASE

19

203-63-K2290

PISTON

20

203-63-K2340

O-RING

21

707-44-10280

RING,PISTON

22

707-39-10520

RING,WEAR

23

707-44-10911

RING

24

203-63-K2050

SCREW,SET

25

203-63-K2730

TUBE

26

203-63-K2740

TUBE

27

07000-13025

O-RING

28

01010-50840

BOLT

29

707-88-96181

BAND

30

707-88-87190

BRACKET

31

01010-51035

BOLT

32

01643-51032

WASHER

33

707-88-96971

BAND

34

707-88-87200

BRACKET

35

07283-22236

CLIP

36

01599-01011

NUT

37

01643-31032

WASHER

38

01643-50823

WASHER

39

01010-51025

BOLT
